Low Ku Band Diplexer
Product Introduction
The Low Ku Band Diplexer is a high-performance diplexer specially designed for Low Ku band communication systems. It can effectively separate or combine signals of different frequency bands, achieve antenna multiplexing, and effectively improve the efficiency and performance of communication systems. This diplexer adopts advanced design and manufacturing processes, featuring outstanding electrical performance and reliability. It can be widely applied in fields such as satellite communication, ground microwave communication, and radar systems.
Product specification
Parameters | Details |
Frenquency Range | 10.7GHz - 12.75GHz |
Insertion Loss | ≤ 0.5dB |
Degree of Isolation | ≥70dB |
Power Capacity | 200W |
Working Temperature | -40℃~+85℃ |
Product Advantages
- Save space and costs：One of the greatest advantages of Low Ku-band diplexers is that they can achieve antenna multiplexing. However, this diplexer separates or combines signals of different frequency bands, enabling the same antenna to handle both transmitted and received signals simultaneously, or signals of different frequency bands. This significantly reduces the demand for the number of antennas, thereby saving the space occupied by the equipment.
- High-signal separation：It has an outstanding signal separation capability, capable of precisely separating signals of different frequency bands and effectively avoiding interference between signals. The Low Ku Band Diplexer, with its advanced design and manufacturing process, can achieve an isolation of over 70dB, ensuring minimal mutual interference between the transmitted and received signals.
- Strong compatibility：This dual-tool has excellent compatibility and can be seamlessly integrated with various communication devices and systems. Whether it is the existing satellite communication systems, ground microwave communication equipment, or the emerging 5G communication base stations, etc., they can all adapt to different device interfaces and communication protocols and can be integrated into the existing systems without large-scale system renovations.
Technical Features
- Filter design：The Low Ku Band Diplexer adopts a combination design of high-performance low-pass and high-pass filters. In a diplexer, these two filters work together. The low-pass filter is responsible for processing signals in the Lower frequency band, while the high-pass filter is responsible for processing signals in the higher frequency band.
- Low-loss materials：This diplexer is made of low-loss materials during the manufacturing process, which have excellent electrical properties and can significantly reduce the energy loss of signals during transmission.
- Optimize structural design：Through meticulous optimization of the internal structure, the Low Ku Band Diplexer has successfully achieved miniaturization while realizing high performance. Its structural design fully takes into account factors such as signal transmission paths and electromagnetic compatibility. It adopts a compact layout and advanced manufacturing processes, reducing unnecessary space occupation and signal interference.
Product application
- Satellite communication：In the field of satellite communication, Low Ku Band Diplexer plays a key role. At the ground station, it is responsible for separating and merging the transmitted signals and the received signals to ensure smooth communication between the satellite and the ground station. On the satellite side, it can help satellites efficiently process communication signals with ground stations, optimize the communication functions of satellites, and enable them to better adapt to the complex space environment and communication requirements.
- 5G base station：In 5G base stations, the application of Low Ku Band Diplexer effectively supports multi-band communication. This diplexer can separate and merge signals of different frequency bands, enabling base stations to utilize spectrum resources more efficiently and enhancing the capacity and performance of communication systems.
- Wireless Local Area Network (WLAN)：In WLAN devices, Low Ku Band Diplexer is capable of achieving dual-band or multi-band communication. This diplexer separates and combines signals from different frequency bands, enabling WLAN devices to simultaneously transmit data on multiple frequency bands, avoiding frequency band congestion and enhancing network speed and stability.
OEM service
- Parameter customization：We offer comprehensive parameter customization services and can flexibly adjust various parameters of Low Ku Band Diplexer according to the specific application requirements of customers.
- Interface customization：To meet the special requirements of different customers' equipment, we offer interface customization services. Whether it is necessary to adapt to non-standard RF interfaces or achieve seamless connection with specific communication devices, we can design and manufacture interfaces that match the interface specifications and requirements provided by customers.
- Customized appearance and logo：In terms of appearance design, we can carry out personalized customization according to the requirements of customers. Customers can choose different shell materials, colors and shapes to adapt to different usage environments and the overall style of the equipment.
FAQ
Q:What is the difference between the Low Ku Band Diplexer and other diplexers?
A:Compared with other diplexers, the Low Ku Band Diplexer mainly achieves the separation and merging of signals in different frequency bands through a combination of high-performance Low-pass and high-pass filters in its working principle, while some traditional diplexers may adopt a relatively simple filtering design. In terms of performance, it has a Lower insertion loss, far Lower than some similar products, which can effectively reduce energy loss during signal transmission. In terms of application scenarios, it focuses on the Low Ku band, which has unique application requirements in fields such as satellite communication and 5G base stations.
Q:How to choose the right model?
A:To select the appropriate Low Ku Band Diplexer model, it is necessary to first clarify the specific frequency range of the application. Secondly, the power capacity should be taken into consideration. For communication systems with a power demand of less than 200W, this diplexer can well meet the requirements. It is also necessary to pay attention to performance indicators such as insertion loss and isolation. If the signal quality requirements are extremely high, a model with Low insertion loss and high isolation should be selected to ensure stable signal transmission and high-quality processing.
Q:What are the precautions during use?
A: When installing the Low Ku Band Diplexer, make sure the connection is firm to avoid unstable signal transmission due to looseness. During the installation process, attention should be paid to the matching of interfaces to prevent incompatibility or poor contact of interfaces. During use, it is necessary to avoid strong electromagnetic interference and keep it as far away as possible from other strong electromagnetic sources. At the same time, attention should be paid to the temperature and humidity of the working environment. It is generally recommended to use it within the temperature range of -40 ℃ to 85℃ to ensure the stability and reliability of its performance.
Contact us
If you are looking for a high-performance and highly reliable Low Ku Band Diplexer, please feel free to contact us at any time. We have a professional technical team that can provide you with detailed product consultation, customized solutions and comprehensive after-sales service. Let's join hands and work together to provide strong support for the optimization of your communication system!
