RF Power Detector
Product Introduction
RF Power Detector is developed to meet the demand for realtime, accurate, and reliable RF power measurement in highfrequency transmission and test scenarios. Traditional power measurement solutions often suffer from large size, narrow frequency coverage, and slow response speed—issues that RF Power Detector overcomes through its integrated circuit design and advanced semiconductor materials. It supports frequency bands from 100kHz to 67GHz and offers measurement ranges from 60dBm to +30dBm, covering lowpower signal monitoring and highpower signal detection. The component is constructed with highstability semiconductor materials and features optional digital interfaces for easy data transmission, making it suitable for both commercial consumer electronics and harsh industrial/defense applications.
Product Specifications
Parameters | Details |
Frequency Range | 10MHz - 40GHz |
Power Measurement Range | -60dBm to +30dBm (average power) |
Measurement Accuracy | ±0.5dB |
Response Time | ≤1μs (standard models) |
Operating Temperature | -40°C - +85°C |
Material | Aluminum |
Product Benefits
- High accuracy & linearity: Advanced semiconductor materials and calibration technology ensure ±0.2dB typical accuracy, avoiding measurement errors caused by signal fluctuations.
- Broad frequency & dynamic range: Covers 100kHz – 67GHz and 60dBm – +30dBm, eliminating the need for multiple detectors in multiband RF systems.
- Miniaturized & lowpower design: SMD packages as small as 0402 save PCB space; passive models consume no power, ideal for batterypowered devices.
- Fast response speed: ≤10ns fastresponse models capture transient RF signals in real time, preventing signal overload or loss.
- Easy system integration: Supports standard analog/digital interfaces and requires no additional calibration components, enabling quick connection to RF circuits or test platforms.
- Environmental robustness: Industrial/defensegrade models resist extreme temperatures，vibration, and electromagnetic interference , maintaining stability in harsh environments.
Technical Features
- Integrated calibration circuit: Builtin temperaturecompensated calibration resistors/capacitors reduce accuracy drift caused by temperature changes, ensuring consistent performance over the operating temperature range.
- Advanced semiconductor process: Adopts GaAs or SiGe process, which reduces signal loss and improves linearity compared to traditional siliconbased detectors.
- Overload protection design: Integrated voltage limiting circuits prevent damage to the detector from sudden highpower RF signals.
- EMI shielding optimization: Metalshielded packages or integrated EMI filters provide >50dB EMI rejection, avoiding interference from external RF signals on measurement results.
- Digital signal processing integration: Highend RF Power Detector models include onchip DSP, supporting functions such as peak/average power calculation, data filtering, and threshold alarm.
Product Applications
- Wireless communication systems: Used in 5G/6G base stations, smartphones, and IoT devices to monitor transmit/receive power, ensuring compliance with signal power standards and avoiding interference.
- Radar & satellite systems: Applied in airborne/naval radar and satellite transceivers to detect pulse RF power, supporting target tracking and signal quality assessment.
- Test & measurement equipment: Integrated into RF signal generators, spectrum analyzers, and network analyzers to calibrate output power, ensuring accurate test results.
- Industrial control & IoT: Deployed in RFbased industrial sensors to monitor signal strength, ensuring stable data transmission.
- Aerospace & defense electronics: Used in avionics communication and electronic warfare systems—defensegrade models meet MILSTD883 standards, resisting extreme temperatures and vibration.
- Consumer electronics: Embedded in wireless routers, Bluetooth devices, and WiFi 6/7 modules to adjust transmit power, optimizing battery life and communication range.
OEM
We provide professional OEM services for RF Power Detector to meet the personalized needs of different industries and customers:
- Parameter customization: Tailor frequency range, dynamic range, and response time according to customer application scenarios.
- Interface & package customization: Design nonstandard output interfaces or custom packages to match customer system requirements.
- Performance optimization: Adjust accuracy or temperature stability for highprecision scenarios.
- Branding & packaging customization: Print customer logos on product packages, customize technical datasheets with customerspecific parameters, and design branded user manuals to align with the customer's brand image.
- Technical collaboration & support: Provide presales RF simulation to verify the detector's compatibility with the customer's system; offer postsales onsite debugging and calibration training to ensure optimal integration of the customized RF Power Detector.
FAQ
Q: What is the difference between active and passive RF Power Detector?
A: Passive RF Power Detector converts RF power into electrical signals without external power, featuring low power consumption and small size. Active RF Power Detector requires a 3.3V/5V DC supply, offering higher accuracy and faster response, but consumes more power. Passive detectors are ideal for lowcost, lowpower scenarios, while active detectors are preferred for highprecision applications.
Q: Can RF Power Detector measure both continuous wave and pulse RF signals?
A: Yes. Standard RF Power Detector models accurately measure CW signals. Fastresponse models with peak power detection function can capture pulse RF signals and calculate peak/average power. For special pulse signals, we provide customized detectors with optimized sampling circuits.
Contact Us
If you need a highaccuracy, broadrange RF Power Detector to solve RF power measurement, signal monitoring, or system calibration challenges in your application, contact us now to get customized solutions tailored to your project requirements!
